MECHANICAL SPECIFICATIONS

Overall diameter

154 mm

Mounting hole diameter

￠102*4-M6 mm

Throat Diameter

38(1.5") mm

Mounting  Type

Bolt-on

Net weight

3.1 kg

ELECTRICAL SPECIFICATIONS

Nominal impedance

8 Ω

DC resistance

6.2 Ω

Nominal power handling

90 W

Continuous power handling

120 W

Sensitivity (1W/1m)

108 ± 2dB

Frequency range (-10dB max)

600-20KHZ Hz

Voice coil diameter

99.2 mm

Voice coil material

Outside 1 Layer CCAR

Former material

katpon

Winding depth

3.2 mm

T yoke

9 mm

Plate

9 mm

Magnet grade

NdFeB 38H

Diaphragm  Material

Titanium

THIELE & SMALL PARAMETERS

Fo

600 Hz

Revc

6.2 Ω

(1) 24 hours in free air according to EIA-426B

(2) 1 inch=25.4mm

(3)Xmax=(Winding depth -Plate)/2
